Koser Residence: Net-Zero Home by Neumann Monson Architects

Koser Residence / Neumann Monson Architects

Project: Koser Residence
Architects: Neumann Monson Architects
Location: Iowa City, Iowa
Size: 2,850 SF
Completed 2017
Photography: Cameron Campbell Integrated Studio
Awards
AIA Central States Merit Award

Pragmatic building strategies and an expressive palette bring zero-energy building performance to a walkable Iowa City neighborhood.

Koser Residence / Neumann Monson Architects

A darkened exterior shell emphasizes the house’s introversion. Spaced boards veil outdoor spaces and selective windows guard slivered glimpses inside. The brooding demeanor is belied by a welcoming overhang that bridges the entry and an intimate outdoor dining nook. Both share smooth cedar siding with a delicate grain that relieves the surrounding rough shakes with inviting, tactile vulnerability. The textural contrast foreshadows the experiential core of the Koser residence, a bright courtyard carved from the house’s crusty perimeter.

Koser Residence / Neumann Monson Architects

The design bears the mark of the 1960’s home that came before it. Removing the existing house’s superstructure and incorporating its slab-on-grade foundation into the new construction makes the most of the predecessor’s limited potential. Additional foundations and a concrete collar support exterior walls of nine- and ten-foot pre-cut studs. Their height differential provides adequate slope to the 14-inch truss-joists spanning the 20-foot width. Operable windows extend to the ceiling plane, maximizing daylight penetration and encouraging cross-ventilation. Foamed-in-place insulation and a continuous rigid insulation shell provides R-24 at the walls and R-40 at the roof. An insulated radiant topping slab, poured and polished before interior walls were framed, serves as a climate-controlling finish floor.

pool / Neumann Monson Architects

Supplementing the radiant floor is a highly efficient, geothermal climate control system coupled to a horizontally-bored loop beneath the parcel. When cooling the home, heat is rejected into the pool via a heat exchanger, further maximizing efficiency. Perched atop the roof, a 10.08kW photovoltaic array powers the mechanical system, car charging station, LED lighting, and EnergyStar appliances.

Koser Residence / Neumann Monson Architects

The property absorbs roof and deck runoff through a sunken raingarden in the rear yard. The garden’s leafy vegetation and soft edges counterpoint the clean, crisply executed pool around which the airy, cedar-clad house wraps.

Koser Residence / Neumann Monson Architects

dining room / Neumann Monson Architects

living room / Neumann Monson Architects

Koser Residence / Neumann Monson Architects

bedroom / Neumann Monson Architects

bathroom / Neumann Monson Architects

Koser Residence / Neumann Monson Architects

house / Neumann Monson Architects

plan
