Prefab Sustainable Home Perched Amidst a Pristine High Desert

Prefab Sustainable Home Perched Amidst a Pristine High Desert

Architect: o2 Architecture
Project: Prefab Sustainable Home / Rock Reach House
Collaborators: Blue Sky Building Systems
Location: Rock Reach / Yucca Valley, California, United States
Photography: Lance Gerber

From the architect: A collaborative effort between o2 architects’ Martin Brunner and Lance O’Donnell and Prefabricated Home developer Blue Sky Building Systems; this 1,000 square foot home is located in the Mojave Desert region at 4,000’ above sea level. The program called for a sustainable, modestly scaled residence to serve as a prototype for a prefabricated line of homes.

Prefab Sustainable Home Perched Amidst a Pristine High Desert 1

Special attention was paid to site placement and building orientation. Inspired by Le Corbusier’s “Domino”; the building contains a pure structure of columns and planes. Adaptability is created by the non-load bearing walls and openings that can be moved within the structure to satisfy a variety of site conditions.

Prefab Sustainable Home Perched Amidst a Pristine High Desert 2

The home is positioned above the site on moment-resisting columns and beams of cold-formed, light gauge steel. The building envelope is composed by a grid of pre-manufactured wall panels and standardized building components. The bathroom module, containing all home MEP systems, is built off-site and delivered finished. Interior spaces are defined by the placement of storage cabinetry, eliminating interior framed walls. Solar technologies provide electricity, hot water and space heating.

Prefab Sustainable Home Perched Amidst a Pristine High Desert 3

The flat-packed building components minimize transportation volume and promote sustainability through material/structural efficiency and can be dissembled and relocated. The inherent nature of prefabricated design ensures low embodied energy and minimizes site waste. The prototype of prefab sustainable home was completed after a construction schedule of 8 weeks and a construction budget of $270/sf.

Prefab Sustainable Home Perched Amidst a Pristine High Desert 4

Prefab Sustainable Home Perched Amidst a Pristine High Desert 5

Prefab Sustainable Home Perched Amidst a Pristine High Desert 6

Prefab Sustainable Home Perched Amidst a Pristine High Desert 11

Prefab Sustainable Home Perched Amidst a Pristine High Desert 7

Prefab Sustainable Home Perched Amidst a Pristine High Desert 8

Prefab Sustainable Home Perched Amidst a Pristine High Desert 9

Prefab Sustainable Home Perched Amidst a Pristine High Desert 10

Prefab Sustainable Home Perched Amidst a Pristine High Desert 12

Prefab Sustainable Home Perched Amidst a Pristine High Desert 13

Prefab Sustainable Home Perched Amidst a Pristine High Desert 14

Prefab Sustainable Home Perched Amidst a Pristine High Desert 15

Prefab Sustainable Home Perched Amidst a Pristine High Desert 16

Prefab Sustainable Home Perched Amidst a Pristine High Desert 17
