Hill Top Cottage / Luigi Rosselli Architects

Hill Top Cottage Luigi Rosselli Architects

Weaving architectural heritage with contemporary design and lifestyle is a practice that rewards with surprises and characterful places.

In a conservative residential pocket close to North Sydney, a workers cottage perches on top of a hill looking south-east towards striking views of Sydney Harbour. The idea behind the design was to retain the existing character of the cottage to the front – its low slung and strong horizontal lines – and place a more contemporary two storey addition at the back behind the ridge. The new upper level is fully clad with CNC routed plywood shutters, it pierces the ample roof plane to the front of the house with a wide dormer window that is curved at the corners.

Internally, the skill of Associate Architect, Sean Johnson and Interior Designer, Romaine Alwill has successfully married the old and the new: polished concrete and the existing dark timber floors, oversized glass sliding windows and the original leadlight sashes. A semi-transparent perforated black steel staircase cascades down through the centre of the house, from an openable skylight in the roof to the ground floor, allowing generous amounts of light to bathe the entrance hall.

The young family who own the cottage hoped to be welcomed by their neighbours, but were met instead with dozens of objections to the design, and a tough council process. However, with hard work to convince the community and the vision and support of key Council representatives, the design was approved with some small modifications (the addition of steps to the rear façade and a redesign of the garage door). Today the family can enjoy their views of the Harbour Bridge and have found acceptance in their community.

Project: Hill Top Cottage
Design Architect: Luigi Rosselli
Project Architect: Sean Johnson
Interior Designer: Alwill Interiors
Builder: Built Rite Pty Ltd
Structural Consultant: Peninsular Consulting Engineers
Joiner: Sydney Joinery http://sydneyjoinery.com.au/
Landscaper: William Dangar Associates
Location: Lower North Shore, Sydney, NSW
Photography: Justin Alexander

Hill Top Cottage Luigi Rosselli Architects 1

Located on top of a high rock ledge, the new additions to this “craftsman’s” style cottage have great Sydney Harbour and city views, framed by adjustable plywood shutters and the lush Will Dangar designed garden. The right hand side step in the first floor elevation was imposed by North Sydney Council to satisfy the concerns of the neighbours.

Hill Top Cottage Luigi Rosselli Architects 2

The oversized living room window opening is framed and protected by an off form concrete lintel, and a slab of polished concrete cantilevers over the lawn. The “Oxblood” or “Pompeian” red mineral paint by Porters Paints is a reminder of the original red brick colour of the house.

Hill Top Cottage Luigi Rosselli Architects 3

The “Craftsman’s” cottage style of the first decades of the 20th century was characterised by a simple gable roof with low eaves that ran parallel to the street with a horizontal elevation, the complete opposite to the California Bungalow style, with its gables facing the front boundary. The first floor attic dormer and garage have been designed with stretched and horizontal proportions. The existing ground floor windows have new sliding plywood shutters. The sandstone walls have adopted the same type of coursing and jointing as the existing stone footings of the house.

Hill Top Cottage Luigi Rosselli Architects 4

The “garden city” ideal town planning concept of the early 20th Century, connected to the “Craftsman” style has been interpreted by the Will Dangar landscaping, large trees have been planted at the front, moulded to the ground contours to facilitate the access to the entry, concealing all the walls and structures behind planting . Next spring we will go back to take photos of the flowering Jacaranda tree.

Hill Top Cottage Luigi Rosselli Architects 5

The curved glass allows uninterrupted views off the living room. Off form concrete frames the window.

Hill Top Cottage Luigi Rosselli Architects 6

Full length sheer curtains soften the living room corner window, high ceilings contrast with the horizontal window stretch. The Alwill Interiors furniture selections also play on contrasts of shape and colour with the Jordan “Nook” sofa, Moroso “Fjord Relax” armchair, the “Coast” leather otterman, Gervasoni pendant light and Jardan Armadillo & Co rug.

Hill Top Cottage Luigi Rosselli Architects 7

The Romaine Alwill selected CULT table and chairs provide warmth and complement the polished concrete slab, anthracite splash back and “Namadji” painted joinery. The kitchen benchtop is a mill finish zinc, constructed by Sydney Joinery with a bevelled edge. The zinc ages more gracefully than stainless steel, it is traditionally used on bistro benchtops in France where “eau de vie” provides a warm patina.

Hill Top Cottage Luigi Rosselli Architects 8

This American Oak bookshelf has CNC routed books as vertical support, complete with book spine and bound covers. To the right we can see the first risers of a stair, leading to the first floor bedrooms.

Hill Top Cottage Luigi Rosselli Architects 9

The stair is the lightwell in the centre of the house, leading to generous openable skylights. The stair balustrade, constructed in perforated steel, allows the light to tumble down, even the upper stair flights are constructed in perforated steel, the layering of the semi-transparent steel sheets create a moire effect.

Hill Top Cottage Luigi Rosselli Architects 10

The perforated steel is finished with a clear lacquer over the raw “black” steel, a mill finish of the mild steel. Welds have been carefully concealed behind minimal edge framing. Behind the balustrade one can see the folded, perforated steps of the second stair flight.

Hill Top Cottage Luigi Rosselli Architects 12

From the first floor landing the stair rises to the roof access hatch. This flight is suspended from the roof frame. A Gorter http://www.gorterhatches.com.au/ glass hatch allows access to check and maintain the array of solar panels on the roof.

Hill Top Cottage Luigi Rosselli Architects 13

The various components of the stair were assembled on site by EJF Engineering

Hill Top Cottage Luigi Rosselli Architects 14

Stairway to Heaven

Hill Top Cottage Luigi Rosselli Architects 14

Sydney Harbour Bridge view from the bed reflected in the Dedece Bertoia “Diamond” reading chair.

Hill Top Cottage Luigi Rosselli Architects 15

The limed American Oak wall panelling behind the bed provides a textured neutral backdrop to Romaine Alwill’s fabrics and furniture.

Hill Top Cottage Luigi Rosselli Architects 16

The dressing room joinery was designed by the project architect, Sean Johnson & Romaine Alwill in collaboration and includes a central drawer and dressing table unit. A slot connects to the ensuite master bathroom.

Hill Top Cottage Luigi Rosselli Architects 17

Why not have a chandelier in your dressing room? The Douglas + Bec “Y” brass and blown glass light feels at home here. The dressing table is built in the central island unit.

Hill Top Cottage Luigi Rosselli Architects 18

An unusual suite of Powder Room and Guest Bathroom, with a mill finish. Matt brass Broadware taps and spouts and Poppham “HEX” encaustic tiles.

Hill Top Cottage Luigi Rosselli Architects 19

The kids’ bathroom “cubby house” feel was accidental, being located in the existing roof space for convenience. The round window on the north face of the house casts a circular sun spot on the limestone floor. The Caroma Blanc bath introduces the children to the lux life

Hill Top Cottage Luigi Rosselli Architects 20

An Aren Bianco limestone texture and limed American oak again offer tonal and textured balance.

Hill Top Cottage Luigi Rosselli Architects 20

This sitting area is in the old house, a smaller room off the living-dining at the back. It is a restful alternative, converted to a study and play area, with a fabric covered pinboard.

Hill Top Cottage Luigi Rosselli Architects 21

Lisa La Pointe artwork “Magi” brings life to the restful dark “Half Masala” Resene paint. The Grasshopper light by CULT and the MUUTO Scandinavian “Around” coffee table.
