The Glass House in Stockholm Archipelago / John Robert Nilsson Architectural Office

The Glass House in Stockholm Archipelago

Architects: John Robert Nilsson Architectural Office
Project: The Glass House
Team: Robert Nilsson, Maria Århammar, Niklas Singstedt, Martin Zetherström, Vincenzo Cassotta
Location: Stockholm Archipelago, Sweden
Area: 250.0 sqm
Photography: Åke Eson Lindman, John Robert Nilsson

Situated on a natural plateau atop a rocky headland, the Glass house enjoys panoramic views across the bay and the evening sun to the west. The Gotland limestone on concrete foundation is crafted like a massive plinth, building walkways along three of the house’s façades under the roof’s deep overhangs. On the side facing the sea, the limestone-covered foundation opens out into a large terrace with a sunken swimming pool and recessed sitting area providing shelter from the wind. The same limestone-covered foundation forms the connected floor space throughout the house.

The Glass House in Stockholm Archipelago 1

The entrance side of the Glass house features a solid façade wall, plastered and decolored to matte black. The only interruption is a ceiling-high pivot door with a thin lattice of black stained oak filtering the light. The other façades are made up of a structural glazing system of full glass walls. The insulated glass consists of an outer layer of Optiwhite glass, reducing daylight discoloration, and an inner layer of thermal control glass to avoid condensation and downdraft. The bottom of the glass frame is completely recessed and hidden between limestone slabs, making the boundary between outside and inside practically non-existent. A hidden moat around the house, constructed of stainless steel with a limestone cover, channels rain and snow water away.

The Glass House in Stockholm Archipelago 2

The floor plan of the Glass house, a simple rectangular shape, is clearly divided into private and social spheres. The private sphere is further divided into bedrooms, bathrooms and storage, built around an open-concept living space. Instead of traditional doors, most openings are ceiling height. Simply turning the corner gives you the impression of entering a new room. The formative idea behind the house was to create a clear and concentrated form in marked contrast to the surrounding landscape. The presence of a concrete object, abstract for the location, also heightens the experience of the rich shades of nature.

The Glass House in Stockholm Archipelago 3

While an agreement on the basic idea was reached quickly, finalizing requirements regarding quality, precision and attention to detail was an extensive project. Behind the clean lines hides a series of advanced technological systems. Tap water is extracted from the sea and treated in a desalination unit. Heating for the floors, outdoor pool and hot water is produced by a geothermal heat pump. District cooling, so-called free air conditioning, is also pumped into the house through the rock shaft, which means that all air-conditioning is basically free of charge. All systems are operated by a smart control and monitoring solution, using a web-based interface, controlled via the internet or a mobile handset.

The Glass House in Stockholm Archipelago 4

The Glass House in Stockholm Archipelago 5

The Glass House in Stockholm Archipelago 6

The Glass House in Stockholm Archipelago 7

The Glass House in Stockholm Archipelago 8

The Glass House in Stockholm Archipelago 9

The Glass House in Stockholm Archipelago 10

The Glass House in Stockholm Archipelago 11

The Glass House in Stockholm Archipelago 14

The Glass House in Stockholm Archipelago 15

The Glass House in Stockholm Archipelago 16

The Glass House in Stockholm Archipelago 12

The Glass House in Stockholm Archipelago 13

The Glass House in Stockholm Archipelago 17

The Glass House in Stockholm Archipelago 18
