Tiny Blackened Timber Cabin in a Forest in Upstate New York

Tiny Blackened Timber Cabin

Architecture: JacobsChang Architecture
Project: Timber Cabin
Location: New York, United States
Photography: Noah Kalina

This 360 sf. timber cabin is located on a remote 60 acre, privately owned second-growth forest in Sullivan County, NY. It is sited on a steep, isolated area of the property with no vehicular access, no piped water and no electricity.

Tiny Blackened Timber Cabin 1

From the outset, the project outlined two formidable directives: to design a structure that can be constructed by amateur weekend builders & to consider a limited construction budget.

Tiny Blackened Timber Cabin 2

The topography presented a difficult challenge. In an effort to minimize sitework (in this case, shovels by hand) and to eliminate the need for large footings, retaining walls and pumped concrete, the architecture is lifted above the ground and relies upon support from the trees. Sonotube footings anchor the upslope corners at grade while half of the weight of the structure is distributed, via Garnier Limbs, to two existing trees.

Tiny Blackened Timber Cabin 3

Engineered wood beams form the perimeter with standard nominal lumber for all intermediate framing. Three 8’x8’ steel-tube pivot doors, the largest single expense, were fabricated offsite and installed, weatherstripped and fitted onsite with dual-insulated glass.

Tiny Blackened Timber Cabin 4

Exterior and interior boards were milled and kiln-dried from the Eastern Pines felled on the property. To minimize maintenance and to withstand long wet winters, exterior boards are treated using traditional Scandinavian pine-tar. Interior walls and ceiling are painted and the floor is protected with a clear matte sealant.

Tiny Blackened Timber Cabin 5

The space is heated with a highly efficient Jotul wood stove and power, if needed, is drawn from a portable generator. The entire construction was performed by its two owners, and in the true spirit of New England barnraising, with a team of dedicated weekend support.

Tiny Blackened Timber Cabin 6

Tiny Blackened Timber Cabin 7

Tiny Blackened Timber Cabin 8

Tiny Blackened Timber Cabin 9
